Diamond Wire- saws for granite quarries

  • Bit Type: Diamond Wire- saws for granite quarries. To be widely used for granite quarries,and for granite mine block squaring.
  • Size: φ12.5mm, φ11.5mm and custom-made
  • Applications: granite quarries
  • Package: 370x370x95 mm per carton

Diamond Tools

Diamond blade
Diamond segment
Diamond/CBN grinding wheel
Polycrystalline diamond compact (PDC cutter)
Diamond grinding tools
Diamond polishing pads
Diamond Core Drill Bits
Diamond Wire Saw Rope
PCD saw blades
  • Product details
  • parameter
 To be widely used for granite quarries,and for granite mine block squaring.




It can be customised according to the information and stone samples provided by the customer, thus improving cutting efficiency and longevity.




 Specification and Technical Parameters of Diamond Beads

Specification (mm)

Height of Work Layer( mm )

Manufacture Technique

φ12.5

6.4

Hot Pressed Sintering

φ11.5

6.4
Hot Pressed Sintering


Specification and Performance Parameters of Diamond Wire-saws

Identification

Specification(mm)

Beads/m

Reinforcement

413R40

φ12.5

40

R/R+S

412R40

φ11.5

40

R/R+S

412R38

φ11.5

38

R/R+S

*P:represents Plastic, R：represents Rubber,S： represents Spring

Cutting Material

Line Speed(m/s)

Cutting Speed(m2/h)

Wire Life(m2/m)

Low Rigidity Granite

33-37

15-20

20-40

Mid-hard Granite

30-37

8-15

12-25

Hard Granite

28-33

4-8

8-15

Abrasive Granite

33-37

8-15

15-30
 Specification and Technical Parameters of Diamond Beads

Specification (mm)

Height of Work Layer( mm )

Manufacture Technique

φ12.5

6.4

Hot Pressed Sintering

φ11.5

6.4
Hot Pressed Sintering


Specification and Performance Parameters of Diamond Wire-saws

Identification

Specification(mm)

Beads/m

Reinforcement

413R40

φ12.5

40

R/R+S

412R40

φ11.5

40

R/R+S

412R38

φ11.5

38

R/R+S

*P:represents Plastic, R：represents Rubber,S： represents Spring

Cutting Material

Line Speed(m/s)

Cutting Speed(m2/h)

Wire Life(m2/m)

Low Rigidity Granite

33-37

15-20

20-40

Mid-hard Granite

30-37

8-15

12-25

Hard Granite

28-33

4-8

8-15

Abrasive Granite

33-37

8-15

15-30
