Sinter and press segment with matrix together to be sintered diamond blade, there are hot press and cold press 2 kinds.
Sintered diamond saw blade feature:
Suitable for the diamond saw blades which diameters are below 230mm
Sintered diamond saw blade application:
General cutting of granite ,marble,masonry ,concrete materials, precise cutting of ceramic tiles,quarry tiles,water flood cooling enhances cutting quality and blade life ,engineering bricks ,and various kinds of construction materials.
Machinery
Hand held saw, circular saw, high speed power saw, Angle grinder, Walk behind saw low hp, Flat saw, Tile saw, Masonry saw, Stone Saw

Parameter：

Outer Diameter		Arbor Size		Segment Dimension	Segment Number
Inches	Metric (mm)	Inches	Metric (mm)
4"	105	7/8"	22.23	32*2.0*8/10	8
4.5"	115	7/8"	22.23	32*2.0*8/10	9
5"	125	7/8"	22.23	32*2.2*8/10	10
6"	150	7/8"	22.23	32*2.2*8/10	12
7"	180	7/8"	22.23	32*2.4*8/10	13
8"	200	7/8"	22.23	32*2.4*8/10	13
9"	230	7/8"	22.23	32*2.6*8/10	16
10"	250	7/8"	22.23	32*2.6*8/10	18
12"	300	1"	25.4	32*3.0*8/10	20
14"	350	1"	25.4	32*3.2*8/10	24
16"	400	1"	25.4	32*3.4*8/10	28
18"	450	1"	25.4	32*3.6*8/10	32
20"	500	1"	25.4	32*3.6*8/10	35
24"	600	1"	25.4	32*4.2*8/11	42

                                                    Other Sizes are upon requirements
